WAVE DG-7661

BODY
WAVE series contour track light has equipped with our latest developed Profile angle: 17-35°/25-36°/ 40°/ 45°/50-60°/68° for option,Family-style design, multi- functions, wide range of applications. shaping.Ultra-high-definition projection.Millimeter-level precise Spot shaping, uniform illumination.
Fixed focus / zoom lens can be switched arbitrarily (It truly integrates fixed-focus optics and zoom optics mutually.
Maximize the optical properties of fixed focus and zoom lens).

LED SOURCES(TOP LED BRAND USED)
Citizen / Cree / Osram / Bridgelux
CRI: 90,95,97
CCT: 2700K, 3000K, 4000K, 5000K,6000K SDCM<3
Other CRI, CCT options,Tuneable white and Dim to Warm versions available by request

DRIVER
Supplied with built-in type driver, easy to installation
Dimming options: 0/1-10V, DALI (DALI DT6/ DALI DT8), Phase Cut, CASAMBI

OPTIC
Beam angle: 20-35°/25-40°/50-60°
Track System
1-Circuit 2 wires
1-Circuit 3 wires
3-Circuit 4 wires
3-Circuit 6 wires
